Aluminium Foil Woven for Thermal Insulation

  • Alloy1060 1050 1100 8011 8021
  • TemperO H14 H24 H18 H22 H32 etc
  • MOQ3TONS
  • PackageWooden Box
  • PortQingdao Tianjin
  • ApplicationInterior Tiles

SEND MESSAGE CHAT NOW Full Spec Sheet

  • Product Details

  • Inquiry

Aluminium Foil Woven For Thermal Insulation Basic Info:
Model NO.: PYS1-2
Color: Silver
Aluminum Foil: 7micron
Woven Fabric: Polyethylene
Standard Width: 1.2m, 1.22m, 1.25m, 1.35m, 1.5m
Reflectivity: 95%-97%
Trademark: SIGMA
Transport Package: Polybag per Roll
Specification: IOS, SGS

Product Name:

Aluminum Foil Woven for Thermal Insulation

Technical Data:

Product name: Roof sparking
Structure:Alu foil/PE/woven/Blue PE coating
Appearance
Silver/Blue
Structure
Aluminum foil/PE/woven/blue PE coating
Width(cm)
1.35m
Length(m)
60m
Gramm age
120gsm
Water vapor Transmission
0.015gsm/KPA
Reflectivity
91%-92%
Tensile strength(MD)
200N/25mm
Tensile strength(TD)
250N/25mm
Bursting Strength
590N
Treatment
FR/VCI/Perforated available
Temperature resistance
4hours no declaiming -30°C/90°C

Aluminium Foil Woven For Thermal Insulation Specification:

Woven fabric weight: 40gsm 60gsm 80gsm
Roll Size: 800mm-1830mm
Length: 20m 30m 50m 100m 20m or customized
Why use Radiant Barrier Housewrap?

Radiant barrier housewrap is widely used in wrapping the house(building), it can keep the
house being homoiothermism, warm in winter and cool in summer.We are the only manufacturer
who produce the radiant barrier housewrap products according to Australia and
USA flame-retardant standard.
How It Works?

One side is 99.7% pure Aluminum foil,it can support 97% sunreflective rates for thermal radiation
shield, another side is blue PE coating, it is antiglare and can protect the workers when installing.
Inside, it is high tear strength PE woven fabric, it has good plasticity function which is easily to
be installed and can cover all corners. Also there are many pin holes on the surface of the foil,
it ensure the materials breathable and moisture.
What Raw Materials We Use?

We use 100% pure materials both Aluminum foil, LDPE and woven, flame-resistant material is used inside.
All of the raw materials are conform to both Australia AS1530.2 and USA ASTM E84 flame-retardant strandard.
How To Install?

1.The regular roll size is 1.35m (width)*60m(length),you\'d better measure the area of the
external wall of the house(building).
2.Wrap the house(buliding), use nail gun to fixed the adiant barrier housewrap with the wood wall
or wood pedestal.Make sure to install the alu side close with the house(building) and blue anti-glare layer ourside.
3.You can add bubble or XPE/EPE foam into the material to improve the thermal insulation.
After the foil installation finished, you can easily decorate the wood, stone cladding or glass
curtain wall as external wall.


Low cost high quality. Good heat insulation. Good insulation properties. Product description. Aluminum foil woven fabric is a new environmentally-friendly heat insulation made of ..., which is soft, light and easy to install. Suitable to be used in roofing insulation as reflection or heat barrier in industrial, commercial, residential buildings and house wrapping. And the woven foil series products are made by highly complex and multi-layer extrusion laminated together, they can be in fire-retardant and non-fire retardant. It depends on customer\'s choice of built environment. Products features:
1. this product tasteless, on-toxic and environmental protection;
2. light and soft, clean, flame retardant, easy to install;
3. with hot reflex, heat insulation, sound insulation, anti-radiation, shockproof, shielding function;
4. moisture proof, sunscreen, waterproof, good sealing, heat insulating and energy-saving;
5. moisture proof, sunscreen, heat insulation;
6. there are heat preservation function in winter, good effect of energy saving. Packing &shipping.
